Degrees of Protection - First Digit

The degree that a person is protected against moving parts is indicated by the first digit of the IP code – so, “2” in the case of an IP20 connector.

This digit also refers to the degree to which equipment is safeguarded against the intrusion of foreign bodies into an enclosure.

An IP20 connector is protected against solid objects up to 12mm in size, which is approximately the size of a person’s fingers.

Degrees of Protection - Second Digit

The degree of protection of the equipment inside the enclosure against the harmful entry of different forms of moisture is indicated by the second digit.

The “0” in IP20 connectors indicates that there is no protection against liquids and they will be susceptible to damage if they come into contact with water or moisture.

A Choice Of IP20 Connectors

Here at Northern Connectors, we stock an extensive range of modular, rectangular, and circular IP20 connectors from world-renowned brands, including CONEC, HARTING, Hirschmann, and Weidmüller.

Our collection of circular connectors from HARTING are not only super easy to use but they come with a variety of termination technologies (e.g. crimp, IDC, and THR) – guaranteeing a quick and cost-effective realisation of all wiring and communication tasks.

Rectangular flanged connectors from CONEC are perfect for commercial and industrial applications that need power, signal, and coaxial connections within one convenient shell.

As with all the products we supply on our website, every IP20 connector is manufactured to the highest quality and meets stringent safety standards. They’re even priced competitively – meaning you needn’t break the bank to connect your crucial devices!

Buy IP20 Connectors from Northern Connectors

If you need an IP20 connector that protects fingers and other small objects, you’re sure to find what you’re looking for on our website.

Take your time to explore all the available options by clicking through and learning more about each product’s features and specifications.

Every product page includes a downloadable manufacturer’s brochure for a more detailed description of the IP20 connector.

However, if you’d like to discuss your requirements with one of our specialists, you’re welcome to do so – we’re open Monday to Friday from 8.45 am until 5.00 pm every day, apart from Friday when we close at 3.45 pm.

Why not give us a call on 01744 815 001?

You can also contact us by sending us an online message, if you prefer.

FAQs:

What is an IP20 connector suitable for?

IP20 connectors are often used indoors for lighting in living rooms, dining rooms, or kitchens where there is little risk of ingress.

These products do not offer protection against water and splashes, so they are not suitable for outdoor use and may not be the best option for bathrooms where moisture levels are high.

To find out more about our range of IP20 connectors and for help choosing the most suitable connectors for your application, please get in touch with our team.

How does an IP20 connector compare with other IP connectors?

An IP20 connector is protected from touch by fingers and objects greater than 12mm in size.

Unlike an IP44 that offers a higher level of protection for smaller objects and resists splashes from every direction, IP20 connectors do not offer protection against liquids and moisture. Instead, they are intended for dry rooms only.

IP65 connectors are completely dustproof and protected against low-pressure water jets from any direction. This means they are more effective for outdoor use than IP20 connectors, as they are less susceptible to damage in adverse weather conditions.

Find out more about our range of IP20 connectors by talking to our experts on 01744 815 001.

How do I order IP20 connectors from Northern Connectors?

Ordering IP20 connectors via our easy-to-navigate website is simple.

All you have to do is scroll through the extensive range of products available and click through to learn more about their features and benefits.

To delve deeper into the product’s specifications, why not download the manufacturer’s brochure (found on every product page)?

Once you’ve identified the perfect IP20 connector for your requirements, fill out the quotation form with your name, contact details, and required part number and quantity.

We’ll then get back to you with a competitive price and, if you’re happy to proceed, we’ll process your order and keep you updated on its progress – so you know when to expect it to be delivered.

If you have any further questions about the IP20 connectors available, don’t hesitate to contact us.
