Hirschmann G Series

The compact dimensions of the G series make it ideal for tough environments that have space limitations.

The G series is often used on power and control applications for small drives in hydraulic and pneumatic systems, electromedical devices and photo cells.

The connectors are offered in two structurally identical versions either with or without earthing contact with numbering to avoid accidental miswiring.

The design and materials of the G series fulfil the specifications as per VDE 0660 and offer protection against dust and sprayed water.

Key features include:

• Available in 2-17 pin variants
• For voltages up to 250V and currents up to 10A
• Compact plug design with space requirement
• Protection class IP65

For a more detailed description of this connector series please see the manufacturer’s brochure which is available to download above.

For a personalised quotation on any of the part numbers seen in this range please complete the ‘Quick Quote’ form or simply call us on 01744 815001.

• No. of Contacts: 2-7
• Locking Mechanism: Central Screw
• Contact Termination: Solder, Screw, Solder Tabs, Crimp
• Wire Gauge Max: 1.00mm²
• Cable Diameter Range: 4-10mm
• Connector Types: Cable to Panel
• Max. Voltage: 50-250V
• Max. Current: 6-10A
• Ingress Protection Max: IP65
• Moulded Cable Option: Yes

Electrical Notes

See literature for derating curves

Safety Notes

Connectors must not be plugged or unplugged under load. Non-observance and improper use can result in personal injury

Ingress Protection Notes

Rating only guaranteed when locked to the proper mating half from the same manufacturer unless stated otherwise

Additional accessories may also be required to maintain IP rating in some instances
