Souriau UTL Series

The Souriau UTL series is a range of rugged circular connectors with a stainless-steel latch coupling system, IP68/IP69K environmental protection and a high UV resistance making them ideal for both indoor and outdoor environments.

The shape of the UTL’s shell allows for blind mating which is ideal for use in areas with restricted access or in dark conditions. The latching mechanism when mated has a positive audible click and gives the user confidence that the connection is secure.

The range has seen popularity on solar, transportation and FTTH/FTTA applications and has flourished in the architectural lighting arena due to its compliance with RS485, DMX and DALI protocols.

Designed and qualified according to the UL1977 and IEC61984 standards, the UTL connector series offers a 5VA flammability rating, hot wire, and current breaking capacity to meet all standards of industrial equipment.

Connectors are available in 4, 5, 6 & 8 way configurations and with a multitude of contact types and termination methods which the user can tailor to suit their needs.

Trim Trio® Connectors – Versatile Industrial Interconnect Solutions

The Souriau UTL Series forms part of the Souriau Trim Trio® industrial connector portfolio.

Trim Trio® refers to the trio of contact options (machined, stamped & formed, highspeed) which can be used with these rugged bayonet or latch locking circular and rectangular connector types.

This unique feature simplifies the supply chain, reduces the complexity of production and gives you the ability to switch from one connector series to another very easily. This allows you to address new customer needs with little fuss or impact on your equipment and production lines. Your product upgrade is easier, faster and without additional costs.

Developed to be compliant with major electrical IEC and UL standards, the Trim Trio® portfolio guarantees safety conditions for the installers, making it the ideal solution for all your industrial and harsh environment needs.

Other Souriau Trim Trio® series include the UTP, UTG, UTS, UTO, UTSX, UTGX, UTOX and SMS Series.

For a more detailed description of this connector series please see the manufacturers brochure which is available to download above.

For a personalised quotation on any of the part numbers seen in this range please complete the ‘Quick Quote’ form or simply call us on 01744 815001

• No. of Contacts: 4, 5, 6, 8
• Locking Mechanism: Latch
• Contact Termination: Crimp, Solder, Dip-Solder, Screw
• Wire Gauge Max: 2.50mm²
• Cable Diameter Range: NA
• Connector Types: Cable to Panel, Cable to Cable
• Max. Voltage: UL, CSA, IEC Ratings Available on Request
• Max. Current: UL, CSA, IEC Ratings Available on Request
• Ingress Protection Max: IP67, IP68, IP69K
• Pre-wired Options: Yes

Electrical Notes

See literature for derating curves

Safety Notes

Connectors must not be plugged or unplugged under load. Non-observance and improper use can result in personal injury

Ingress Protection Notes

Rating only guaranteed when locked to the proper mating half from the same manufacturer unless stated otherwise

Additional accessories may also be required to maintain IP rating in some instances
