binder M12-B Coded (715, 766 Series)

M12 has quickly become an industry standard for sensor and automation applications and is one of the most common connections seen in this environment.

The compact design and versatility of this series makes it Ideal for many applications and therefore an array of coding options have been developed to separate one sub series from the other allowing simpler identification and to tailor certain features towards a particular specification.

Binder M12-B coded connectors are available with 3, 4 and 5 way layouts with many shell variation and moulded cable options.

For a more detailed description of this connector series please see the manufacturers brochure which is available to download above.

For a personalised quotation on any of the part numbers seen in this range please complete the ‘Quick Quote’ form or simply call us on 01744 815001

• No. of Contacts: 3-5
• Locking Mechanism: Screw
• Contact Termination: Solder, Dip-Solder, Screw, Wire Clamp, SMT
• Wire Gauge Max: 0.75mm²
• Cable Diameter Range: 4-8.6mm
• Connector Types: Cable to Panel, Cable to Cable
• Max. Voltage: 125-250V
• Max. Current: 4A
• Ingress Protection Max: IP67
• Pre-wired Options: Yes

Electrical Notes

See literature for derating curves

Safety Notes

Connectors must not be plugged or unplugged under load. Non-observance and improper use can result in personal injury

Ingress Protection Notes

Rating only guaranteed when locked to the proper mating half from the same manufacturer unless stated otherwise

Additional accessories may also be required to maintain IP rating in some instances
