HUMMEL M23 Power & Hybrid Series

The waterproof robust circular M23 Power connector series from HUMMEL is ideal for use in tough environments.

Sealed to IP67 and IP69K in mated condition, the M23 system provides a ruggedised sealed connection at all times, while pin counts are available in a range from 6 to 12 and the current carrying capacity stands at 28A.

A number of cable clamping ranges are available, while cable connectors come in both straight and angled orientation. Both rear and front mount options are available for the panel connectors, both with or without built-in rear cable strain relief.

Inventory levels can be effectively reduced thanks to inserts, contacts and shells containing their own individual part numbers, which can also enable users to adjust the setup to meet their specific requirements.

For a more detailed description of this connector series please see the manufacturer’s brochure which is available to download above.

For a personalised quotation on any of the part numbers seen in this range please complete the ‘Quick Quote’ form or simply call us on 01744 815001.

• No. of Contacts: 6-12
• Locking Mechanism: Screw, Twist Lock (Twilock & Twilock-S)
• Contact Termination: Crimp
• Wire Gauge Max: 4.00mm²
• Cable Diameter Range: 7-17mm
• Connector Types: Cable to Panel, Cable to Cable
• Max. Voltage: 160-630V
• Max. Current: 8-28A
• Ingress Protection Max: IP67, IP69K
• Moulded Cable Option: On Request

Electrical Notes

See literature for derating curves

Safety Notes

Connectors must not be plugged or unplugged under load. Non-observance and improper use can result in personal injury

Ingress Protection Notes

Rating only guaranteed when locked to the proper mating half from the same manufacturer unless stated otherwise

Additional accessories may also be required to maintain IP rating in some instances
