binder M16 IP40 (581, 680, 682 Series)

binder’s M16 IP40 Miniature Connectors are a wide range of low-cost circulars with IP40 environmental protection.

The M16 series is historically one of binder’s most popular ranges due to its fine balance of cost, durability and versatility.

The series offers a lot of scope with pin counts ranging from 2-8 way with 1.50mm² wire gauge, 12-19 way with 0.25mm² wire gauge and a high density option of 24 way with 0.14mm² wire gauge.

Cable versions have straight or angled orientation, shieldable or non-shieldable backshells and are available in either solder, screw or crimp termination. Panel receptacles are available in either front or rear fastened, with solder cup or crimp contacts or with dip solder pins or flexible PCB for board use.

For a more detailed description of this connector series please see the manufacturers brochure which is available to download above.

For a personalised quotation on any of the part numbers seen in this range please complete the ‘Quick Quote’ form or simply call us on 01744 815001

• No. of Contacts: 2-24
• Locking Mechanism: Screw
• Contact Termination: Solder, Dip-Solder, Screw, Crimp
• Wire Gauge Max: 1.50mm²
• Cable Diameter Range: 4-8mm
• Connector Types: Cable to Panel, Cable to Cable
• Max. Voltage: 60-250V
• Max. Current: 1-7A
• Ingress Protection Max: IP40
• Pre-wired Options: Yes

Electrical Notes

See literature for derating curves

Safety Notes

Connectors must not be plugged or unplugged under load. Non-observance and improper use can result in personal injury

Ingress Protection Notes

Rating only guaranteed when locked to the proper mating half from the same manufacturer unless stated otherwise

Additional accessories may also be required to maintain IP rating in some instances
