binder M12 D-Coded / M12 X-Coded (825, 876 Series)

binder M12 D-coded series are a range of metal-shelled circular connectors for industrial networks and harsh commercial environments.

The connectors are available with various termination technology, shell designs and cable specification, all aimed at providing quick and easy installations.

Connectors feature innovative features such as Iris Springs for quick and reliable termination between the plug and the cable shield.

binder M12 X-Coded versions are ideal for industrial network applications in harsh environments and offer transmition rates up to 10 Gbps and conform to IEC 61076-2-109.

The range boasts variants such as male to male double-ended cordsets and male M12 to male RJ45 CAT6A cordsets. All cordsets are available in standard 2, 5 and 10 meter lengths.

For a more detailed description of this connector series please see the manufacturers brochure which is available to download above.

For a personalised quotation on any of the part numbers seen in this range please complete the ‘Quick Quote’ form or simply call us on 01744 815001

• No. of Contacts: 4 & 8
• Locking Mechanism: Screw
• Contact Termination: Solder, Dip-Solder, Screw, Crimp, IDT, SMT
• Wire Gauge Max: 0.75mm²
• Cable Diameter Range: 5-8mm
• Connector Types: Cable to Panel, Cable to Cable
• Max. Voltage: 250V
• Max. Current: 4A
• Ingress Protection Max: IP67
• Pre-wired Options: Yes

Electrical Notes

See literature for derating curves

Safety Notes

Connectors must not be plugged or unplugged under load. Non-observance and improper use can result in personal injury

Ingress Protection Notes

Rating only guaranteed when locked to the proper mating half from the same manufacturer unless stated otherwise

Additional accessories may also be required to maintain IP rating in some instances
